Bluetooth health monitoring watch, with heart rate, exercise volume, body temperature monitoring, Bluetooth AOA positioning, SOS and other functions, can meet the health and sports monitoring, at the same time can do position trajectory management, suitable for campus students, community elderly, sports crowd, effectively solve the problem of health and safety management. Provide product development interface, support docking service and support product customization development.
Inquiry
B10 intelligent health management watch (hereinafter referred to as "B10") is a multi-functional intelligent management watch with health monitoring and location management as the core, including health, exercise, GPS, SOS, NFC, reminder, information receiving and other functions. It focuses on monitoring heart rate, body temperature, blood oxygen, blood pressure, ECG, stroke risk warning and other health conditions, and is specially designed for middle-aged and elderly people and people in need of chronic diseases,It can be applied to hospitals, nursing homes, home care and other scenes.The device integrates LED display, multi-sensor (acceleration, heart rate, body temperature, blood oxygen, ECG) and other core devices, with built-in upgraded nrf52840 chip, which improves the overall stability and operation performance of the host, and makes the device have super processing ability of complex information. At the same time, the device has the triple positioning functions of Bluetooth indoor and outdoor, GPS and A-GPS, which can realize different functions according to the needs of different scenesIt is a smart assistant to protect the health and safety of the elderly.
essential information | |
Host size | 46mm *46mm * 15mm |
Host material | LDS plastic + silica gel |
screen | Ultra low power LCD display |
Screen size | 240*240 |
Control mode | Full screen touch + mechanical buttons |
Waterproof grade | IP67 |
NFC label | Passive / 13.56M / guomi CPU card |
SOS | Long press SOS key for 3 seconds in the power on state to open the positioning and communication and send the distress information |
Core parameters | |
Motherboard chip | NRF52840 |
storage | 64MB FLASH |
Bluetooth version | BLE4.2 |
Bluetooth band | 2.4GHz |
Bluetooth antenna | Built in LDS antenna |
GPS mode | Support Beidou and GPS dual satellite navigation system Support AGPs technology; GPS accuracy < 50m, clock in or press SOS key to start GPS (1: clock in and start GPs need GSM to send location information; 2: press SOS key to start calling and start GPS to upload location information at the same time;) |
GPS antenna | Built in LDs |
Mobile network- Mode / band | Nb-iot band information: B3 / B5 / B8 / B18 / B26 Data transmission: single tone: up to 25.5 Kbps (downlink) / 16.7 Kbps (uplink) Multi tone: up to 25.5 Kbps (downlink) / 62.5 Kbps (uplink) |
Mobile network antenna | Built in LDs |
Temperature sensor | support |
Acceleration sensor | support |
Heart rate sensor | support |
gyro sensor | support |
EKG Sensor | support |
Blood oxygen sensor | support |
Geomagnetic sensor | support |
Air pressure sensor | support |
Ambient temperature sensor | support |
Electrical performance parameters | |
Battery type | 3.7V lithium battery |
Battery capacity | 430mAh |
Charging mode | Clip on charging |
Charging time | 2.5h |
Standby time | Standby for 15 days / continuous working for 7 days |
Data upload | |
Heart rate monitoring | Continuous monitoring / 1Hz / upload every 5 minutes |
Blood pressure trend monitoring | 5Minute hand monitoring once, upload once |
Continuous monitoring of blood oxygen | 5Minute hand monitoring once, upload once |
Diagnosis and treatment of abnormal ECG | Report the incident and upload it when there is measurement |
Fall alarm | Report the incident and upload it when there is measurement |
Activity data tracking | Steps, calories, mileage, late expansion, stair climbing, 5 minutes upload |
Motion data tracking | Sports event reporting, type, duration, core parameter statistics |
matters needing attention
l The device is equipped with a built-in battery which can not be removed. Please do not replace the battery by yourself to avoid damaging the battery or the device;
l The equipment is IP67 waterproof, which can meet the requirements of daily waterproof, such as hand washing, shower, etc., but it is not recommended to soak in water for a long time;
l Use of unauthorized or incompatible power supply, charger or battery may cause fire, explosion or other hazards;
l Do not put the equipment near the heat source, open fire or the place where high temperature may occur, otherwise the battery may catch fire or explode;
l In order to ensure the service life of the equipment, do not place the equipment in direct sunlight, such as the dashboard or windowsill of the car.
B10 smart watch can be used in pension institutions, hospitals, community pension platforms, health monitoring and location safety management of the elderly at home
